Liebert ESU 3 Phase
Liebert ESU is single / three phase output, bi-directional inverter system. ESU operates in parallel with the grid utility. Solar Photovoltaic panels convert solar energy into electrical energy as DC power. This DC power is used to charge the batteries through a charge controller and also used for the load through inverter. Additional energy is exported to the grid.
Specifications: Liebert ESU: 10-100 kW, 3 Phase
| Parameters |
SPECIFICATIONS |
| Parameters |
10wk | 20wk | 30wk | 50wk | 100wk |
| inverter model | Liebert ESU: 030 -bidirectional true sine wave |
| input array input | 100-220VDC | 200-240VDC |
| max .open circuit voltage | 220VDC |
240VDC |
| mppt voltage range | 110V to 198VDC | 220 to 396VDC |
| charger controller | MPPT |
| bettery |
| Voltage | 120VDC | 240VDC |
| max .grid charging current | 74A | 74A | 111A | 185A | 370A |
| type | SMF/lead acid wet cel |
| output |
| power capacity | 10kw | 20kw | 30kw | 50kw | 100kw |
| load power factor | 0.6lag to unity |
| voltage/frequency | 415vac,three phase ,50 HZ(+/-3hz)stand alone mode |
| regulation | +/-2% |
| voltage distortion | <2%at linear load<5%at non linear load |
| grid traking voltage/frequency | 415V,three phase(+/-10%).50Hz(+/-3Hz) |
| over load | 125% for 4 minutes and 150% for 1minute |
| peak efficiency (1) | 91% | 91% | 93% | 92% | 92% |
|
perating modes |
1.Stand alone 2.grid interactive 3.off line |
| environmental | |
| Operating temperature | 0 - 400 C |
| storage temperature | -10to +550C |
| relative humidity | Upto 95%RH non condensing |
| acousitics noise | <62dB | <62dB |
| altitude | <1000meter above sea level |
| mechanical | |
| IP | IP 20 |
| cooling | forced cool |
| dimension WxDxH | 400x800x1000 | 550x900x12000 | 1200x1000x1900 |
| weight in kg.(approx.) | 250 | 400 | 800 | 1115 |
| LCD display | Inbuilt |
| monitoring(optional) | RS 232(PCUMON)/MODBUS |
| standard | IEC 62040-3 |
